Amplifier program power
2500 W (LF) + 500 W (HF) Class D Bi-amplified
Input sensitivity
8 dBu – 1.94 V
Input impedance
20 KΩ Balanced
Mains
Universal switch mode Power Supply 85-265 V / 45-65 Hz
Average current draw
3.3 A (Heavy duty musical program)
SPL (1m)
136 dB continuous , 139 dB peak
Built-in DSP
64- bit processing unit. Includes factory presets
AD/DA converters
24 bit – 48 kHz – SNR > 112dB
Presets
FR_FLAT, FR_LONGTHROW, HPF90_FLAT, HPF90_LONGTHROW + 25 configurable user memories
Frequency response (-10 dB)
58 Hz – 19 kHz
LF
2 x 10″ neodymium woofers (2″ voice coil)
HF
3” titanium diaphragm, neodymium magnet compression driver
Directivity (HxV)
80º x 60º / 60º x 80º (rotated horn)
Dimensions (HxWxD)
704 x 330 x 460 mm
Weight
28 kg
Finish
Multilayer baltic birch plywood with high resistant black Polyurea® coating and protective rubber profiles
Grille
1.5 mm steel with grey micro-foam cloth
Connectors
1x XLR input / 1x XLR link / 1x AC PowerCon® input / 1x AC PowerCon® link / 1x EtherCon® RJ45 input / 1x EtherCon® RJ45 link
