Light Source Type
Discharge
Light Source Quantity
1
Light Source Power
310 W
Life Expectancy
3000 h
Illuminance @ 5 m
1844589 lx
Luminous Flux (Total)
33344 lm
CRI
76.2
CCT
6900 K
Optical
Beam Angle Minimum (Circular)
0.6 °
Cutoff Angle Minimum (Circular)
2.4 °
Field Angle (Circular)
1.7 °
Frost
Yes
Focus
Motorised
Control and Programming
Control Mode
Auto, DMX, Manual
DMX Channels
15, 20
Protocols
CRMX Classic, DMX, W-DMX, RDM
Wireless
LumenRadio
Display
Battery, Gravity Sensor, TFT
Dynamic Effects
Dimmer
0-100 %
Strobe
0-15 Hz
Shutter
Yes
Prism 1
8-facet Circular
Prism 2
5-facet Linear
Colour System
Colour Wheel
Dichroic Colour Wheel 1
14 + Open
Gobo System
Metal
Gobo Wheel 1
17 + Open
Movement
Pan
540 °
Tilt
260 °
Pan/Tilt Resolution
16-bit
Electrical Specifications and Connections
Power Supply
100-240 V AC 50/60 Hz
Power Consumption
445 W
Fuse
8 A
Power Connector In
Power Pro True
Power Connector Out
Power Pro True
DMX Connector
XLR 5P In/Out
DMX Connector In
XLR 5P
DMX Connector Out
XLR 5P
Data Connector
etherCON In/Out
Data Connector In
RJ45
Data Connector Out
RJ45
Mechanical Specifications
Length (mm)
256 mm (10.079″)
Width (mm)
370 mm (14.567″)
Height (mm)
591 mm (23.268″)
Weight
20 kg (44.092 lb)
IP Rating
IP65
Housing
Magnesium die-cast
Colour
Black
Product Properties
Cooling
Forced Convection
Thermal Specifications
Maximum Ambient Temperature
45 °C (113 °F)
Minimum Operating Temperature
-10 °C (14 °F)
Included Items
Included Cables
Power Pro True Cable
Included Rigging
Quick-Lock Bracket
