Light Source Type
Discharge
Light Source Quantity
1
Light Source Power
420 W
Life Expectancy
3000 h
Illuminance @ 5 m
1323098 lx
Luminous Flux (Total)
32970 lm
CRI
76.4
CCT
6900 K
Optical
Beam Angle Minimum (Circular)
0.6 °
Beam Angle Maximum (Circular)
31.9 °
Cutoff Angle Minimum (Circular)
1.9 °
Cutoff Angle Maximum (Circular)
50.7 °
Field Angle Minimum (Circular)
1.6 °
Field Angle Maximum (Circular)
47.6 °
Zoom Type
Motorised
Frost
Yes
Focus
Motorised
Control and Programming
Control Mode
Auto, DMX, Manual
DMX Channels
20, 27
Protocols
CRMX Classic, DMX, W-DMX, RDM
Wireless
LumenRadio
Display
Battery, Gravity Sensor, TFT
Dimmer Resolution
16 bit
Focus Resolution
16 bit
Zoom Resolution
16 bit
Frost Resolution
8 bit
Dynamic Effects
Dimmer
0-100 %
Strobe
0-15 Hz
Prism 1
8-facet Circular
Prism 2
6-facet Linear
Prism Overlay
Yes
Colour System
Colour Wheel
Dichroic Colour Wheel 1
13 + Open
Gobo System
Glass + Metal
Gobo Wheel 1
9 + Open
Gobo Wheel 2
16 + Open
Movement
Pan
540 °
Tilt
260 °
Pan/Tilt Resolution
16-bit
Electrical Specifications and Connections
Power Supply
100-240 V AC 50/60 Hz
Power Consumption
660 W
Fuse
10 A
Power Connector In
Power Pro True
Power Connector Out
Power Pro True
DMX Connector
XLR 5P In/Out
DMX Connector In
XLR 5P
DMX Connector Out
XLR 5P
Data Connector
etherCON In/Out
Data Connector In
RJ45
Data Connector Out
RJ45
Mechanical Specifications
Length (mm)
254 mm (10″)
Width (mm)
370 mm (14.567″)
Height (mm)
705 mm (27.756″)
Weight
26.5 kg (58.422 lb)
IP Rating
IP65
Housing
Magnesium die-cast
Colour
Black
Product Properties
Cooling
Forced Convection
Thermal Specifications
Maximum Ambient Temperature
45 °C (113 °F)
Minimum Operating Temperature
-10 °C (14 °F)
Included Items
Included Cables
Power Pro True Cable
Included Rigging
Quick-Lock Bracket
